DH Robotics PGS-5
Spec
| Gripping Force (Per Jaw) | 3.5~5 N |
| Stroke | 5 mm |
| Recommended Workpiece Weight | 0.05 kg |
| Opening/Closing Time | 0.3 s |
| Repeat Accuracy (Position) | ± 0.01 mm |
| Noise Emission | ＜ 50 dB |
| Weight | 0.2 kg |
| Driving Method | Wedge Cam |
| Size | 95 mm x 67.1 mm x 86 mm |
| Communication Interface | Digital I/O |
| Rated Voltage | 24 V DC ± 10% |
| Rated Current | 0.1 A |
| Peak Current | 3 A |
| IP Class | IP40 |
| Recommended Environment | 0~40°C, under 85% RH |
| Certification | CE，FCC，RoHS |
