DH Robotics RGI-14
Spec
| Gripping Force (Per Jaw) | 10~35 N |
| Stroke | 14 mm |
| Sustained Torque | 0.25 N·m |
| Static Torque | 0.4 N·m |
| Rotary Range | Infinite Rotating |
| Recommended Workpiece Weight | 0.7 kg |
| Maximum Rotation Speed | 1500 deg/s |
| Repeat Accuracy (Swiveling) | ± 0.02 deg |
| Repeat Accuracy (Position) | ± 0.02 mm |
| Opening/Closing Time | 0.3 s |
| Weight | 1 kg |
| Size | 178 mm x 50 mm x 50 mm |
| Communication Interface | Standard: Modbus RTU (RS485), Digital I/O Optional: TCP/IP, USB2.0, CAN2.0A, PROFINET, EtherCAT |
| Rated Voltage | 24 V DC ± 10% |
| Rated Current | 1.1 A |
| Peak Current | 2 A |
| IP Class | IP40 |
| Recommended Environment | 0~40°C, under 85% RH |
| Certification | CE，FCC，RoHS |
